Zadní (modrá)
| Číslo na výkresu |
Název součástky Kód součástky |
Sklad | Cena | ||
|---|---|---|---|---|---|
| 01 | REAR WHEEL AXLE 6NT1-110001 | Skladem | 638,35 Kč | ||
| 02 | SHAFT SLEEVE(LH), REAR WHEEL A000-110002 | Skladem | 232,13 Kč | ||
| 03 | NUT M10x1.25 30204-102810 | Skladem | 15,54 Kč | ||
| 04 | STUD, AM10x1.25×25 30020-102025410 | Skladem | 46,61 Kč | ||
| 05 | REAR SPROCKET A000-110004 | Skladem | 1 351,67 Kč | ||
| 06 | OIL SEAL, FB35x52x8 30501-035800N | Skladem | 62,15 Kč | ||
| 07 | CIRCLIP FOR HOLE 52 30800-05205 | Skladem | 31,07 Kč | ||
| 08 | BEARING, 6205-2RS 30400-02503 | Skladem | 186,44 Kč | ||
| 09 | SEAT, SPROCKET MATTE BLACK A000-110006-0B20 | Skladem | 4 505,56 Kč | ||
| 10 | COLLAR, SPROCKET SEAT A000-110005 | Skladem | 232,13 Kč | ||
| 11 | BEARING, 6204-RS 30400-02001 | Skladem | 174,09 Kč | ||
| 12 | DAMPER, SPROCKET SEAT A000-110007 | Skladem | 62,15 Kč | ||
| 13 | REAR RIM COMP. 6NT1-110200-0E800 | Není skladem | |||
| 14 | CENTER SPACER,REAR RIM A000-110008 | Skladem | 203,11 Kč | ||
| 15 | OIL SEAL A000-110201 | Skladem | 46,61 Kč | ||
| 16 | WASHER , REAR WHEEL AXLE 6NT1-110003 | Skladem | 139,83 Kč | ||
| 17 | WASHER , REAR WHEEL AXLE 6NT1-110002 | Skladem | 15,54 Kč | ||
| 18 | NUT, REAR WHEEL A000-110011 | Skladem | 116,06 Kč | ||
| 19 | COTTER PIN, 4.0×35 30903-0403540 | Není skladem | |||
| 20 | Pneumatika 30705-1716 | Není skladem | |||
| 20 | REAR TIRE 30705-1702 | Není skladem | |||
| 20 | REAR TIRE 30700-1701 | Není skladem | |||
| 20 | TIRE, 160/60ZR17M/C(69W) METZELER, ENVIRONMENTAL MERIDIAN VACUUM TIRE 30705-1720 | Skladem | 3 146,00 Kč | ||
| 21 | VALVE, INFLATION 5190-070030-1000 | Skladem | 43,52 Kč | ||
| 22 | CHAIN 3120913 | Skladem | 2 790,33 Kč | ||
| 22 | CHAIN 3120908 | Skladem | 4 980,11 Kč | ||
| 23 | O-RING, 60×3.55 30503-060000N | Skladem | 31,07 Kč | ||
